EasyMark™ Antimetal NFC Tag 25mmNTAG215Round 10pcs

$21.99 inc. GST

  • Round semi rigid antimetal NFC tag suitable for a many applications
  • Ø25mm diameter
  • EasyMark™ surface
  • PVC material for durability and good protection of the integrated chip and antenna
  • T2 grade antimetal layer has a thin profile
  • 3M 467MP
  • Suitable for most applications including vCard
  • NTAG215 chip has 504 bytes of user memory
  • Suitable on metal or carbon fiber surfaces
  • Reprogrammable and securable
  • Please read THIS BLOG for iPhone users

Performance

Smaller tags have average performance in terms of read range and interaction area. A Ø25mm tag read range is between 0-2cm. The tag must be aligned with the phone’s NFC antenna for a successful read.


ORDER NOTES. Please read below before placing an order!

  1. Lead time is only an estimate which is up to 5 working days for stock products. This could be extended during busy periods or delay caused by incorrect order information. Lead time excludes delivery time.
  2. We work on a First-In-First-Out (FIFO) order schedule for stock and custom orders. We don’t expedite orders base on your time constraint. This keeps our ordering system fair for everybody. Please get in touch before placing an order that is less than our estimated lead time.
  3. Double check you have all the order requirements you need filled out such as programming. We make what you order. If requirements such as programming are not filled out, we do not program the NFC chip.
  4. A phone must have NFC and is turned on to use this tag.
  5. Depending on use, cosmetic damage such as scratches, abrasions and material wear will show overtime.
  6. Need volume pricing or want to resell? Get in touch HERE
Availability: Out of stock Category:

Description

Antimetal NFC Tag 25mmNTAG215Round

Antimetal NFC Tag 25mmNTAG215Round chip available user memory is 504 bytes.  It is able to store a URL link up to 490 characters or text up to 492 characters.

Made from durable PVC.

EasyMark™ surface makes it easy to mark.

The 3M adhesive has excellent moisture, solvent, UV and temperature resistance. Sticker has excellent shear strength. It provides good adhesion on flat surface only.

Additional information

Chip Type

NTAG215

Colour

White

Material

PVC (Polyvinyl chloride)

Material Finish

EasyMark™

Size

25mm Diameter

Characteristics

Ambient Temperature -25 to 70 Degrees, Input Capacitance 50.0 pF (picofarads), Input Frequency 13.56 MHz (megahertz), Retention Time Up To 10 Years at ambient temperature of 22 Degrees, Write Endurance Up To 100'000 Cycles at Ambient Temperature of 22 Degrees

Frequency

13.56 MHz (Mega Hertz)

Limiting Values

Input Current 40 mA (milliampere), Storage Temperature -55 to 125 Degrees

Antimetal Layer

T2 Grade
